AA Oil Free Series 5-15 HP
AA Oil Free Series 5-15 HP

The Environmental Solution

  • Cool Clean Air
  • Self-Contained System
  • No Make-Up Water Required
C Series 5-30 HP
C Series 5-30 HP

Industrial Electric

  • Energy efficient
  • Quiet – 68dba
  • TEFC motor
  • 208/230/460/3/60 voltage
  • Microprocessor controlled
  • Single phase 5-10 hp, tri-voltage 10-30 hp
M Series 5, 7.5, 10 HP
M Series 5, 7.5, 10 HP

Industrial Electric

  • Three phase open drip motor options include 200/208/230/460/575 volts
  • Full voltage magnetic starter with 115-volt control power
  • Instrumentation includes line pressure gauge, oil temperature gauge, and hour meter
  • Automatic dual control
  • Spin on type oil filter and separator elements provide for ease of maintenance
  • Tank mount, elevated platform and acoustical enclosure options available
D Series 15-40 HP
D Series 15-40 HP

Industrial Electric

  • Microprocessor controller with sequencer, lead-lag and remote monitoring for up to 8 machines
  • NEMA 1 ODP premium efficient three phase, 60 Hz, 200/208/230/460 or 575 volt motor
  • The motor starter has a NEMA 1 enclosure, 208/230/460/575 volt, with full magnetic voltage (MFV) starter with 110-volt controls, ETL listed, solid state control circuit breaker protection and three phase overload with external reset and phase protection
  • The air end, manufactured by Sullivan-Palatek, has advanced rotor design features; oversize radial thrust bearings, and precision working rotary screws that provide virtually no wear
  • Coupling and drive: compressor is flange mounted to motor C-face for positive alignment and directly coupled for increased efficiency
  • Cooling system equipped with double pass air-cooled aftercooler with thermostatic control for maintaining the appropriate oil operating temperature to within 15 degrees of ambient
  • Oversized dry type air intake filter with easily replaceable elements
  • One-piece lube fill elbow and level sight glass, a vented cap for pressure release when removing
  • Inlet/check valve features a one-piece housing for dependable performance and complete modulation
DG Series 25-50 HP
DG Series 25-50 HP

Industrial Electric

  • Microprocessor controller with sequencer, lead-lag and remote monitoring for up to 8 machines
  • NEMA 1 ODP premium efficient three phase, 60 Hz, 200/208/230/460 or 575 volt motor
  • Motor starter has a NEMA 1 enclosure, 208/230/460/575 volt, with magnetic full voltage (MFV) starter with 110-volt controls, ETL listed, solid state control circuit breaker protection and three phase overload with external reset and phase protection
  • The air end, manufactured by Sullivan-Palatek, has advanced rotor design features; oversize radial thrust bearings, and precision working rotary screws that provide virtually no wear
  • Couplings and drive: compressor is flange mounted to motor C-face for positive alignment and directly coupled for increased efficiency
  • Cooling system equipped with double pass air-cooled aftercooler with thermostatic control for maintaining the appropriate oil operating temperature to within 15 degrees of ambient
  • Oversized dry type air intake filter with easily replaceable elements
  • One-piece lube fill elbow and level sight glass, vented cap for pressure release when removing
  • Inlet/check valve features a one-piece housing for dependable performance and complete modulation
CDD Packages
CDD Packages

Compressor/Desiccant Dryer Packages

  • Unload shutdown
  • The solid aluminum hard coat anodize provides superior strength and corrosion resistance
  • Pre-filtration units can handle up to a quart of liquid per minute
  • Offers low dew points, and consistently drops relative humidity below 10%
  • No need for float drains on the pre-filtration parts
DS Oil Free Series 75-350 HP
DS Oil Free Series 75-350 HP

Oil Free Compressor

  • Easy maintenance access through large double hinged doors
  • Sound attenuation enclosure for quiet operation as standard supply
  • Two Stage Air End design with synchronous gearbox and
  • Rotors have patented super coating for long life
  • PLC touch screen controller with built-in safety shutdowns
  • Optional Variable Speed Drive (VSD) control technology available
  • Wye-Delta starter and Hi-Efficiency TEFC motors as standard supply
  • Air Cooled packages as standard available up to 150 hp
  • Water Cooled Packages from 75-350 hp
  • Double Seal labyrinth design ensures supply of true oil-free air
  • Engineered as a package for ease of installation and operation
UD Series 40-60 HP
UD Series 40-60 HP

Industrial Electric

  • Three phase open drip motor options include 200/208/230/460/575 volts
  • Full voltage magnetic starter with 120-volt control power
  • Comes standard with a T1 Controller capable of sequencing up to seven compressors (gauges optional)
  • One-piece inlet/check valve housing for dependable performance and complete modulation
  • Heavy duty dry type air intake filter with easily replaceable elements
SP16 Series 75-125 HP
SP16 Series 75-125 HP

Industrial Electric

  • Three phase open drip motor options include 200/208/230/460/575 volts
  • Full voltage magnetic starter with 115-volt control power
  • Equipped with an enhanced display Q1 microprocessor, the controller is capable of web access monitoring and sequencing up to 12 compressors
  • SP16-Series air end manufactured by Sullivan-Palatek
  • One-piece inlet/check valve housing designed for dependable performance
  • The compressor is flange mounted to motor C-face for positive alignment
SP20 Series 125-300 HP
SP20 Series 125-300 HP

Industrial Electric

  • Three phase open drip motor options include 460/575 volt, optional 200/208/230 volt on 125 hp units
  • 460-volt MFV with 115-volt control
  • This unit includes a one-piece inlet/check valve housing for reliable performance
  • Manufactured with a display Q1 microprocessor, the controller is capable of web access monitoring and sequencing up to 12 compressors
  • The compressor is flange mounted to motor C-face for positive alignment
  • The air intake filter includes an oversized dry type with easily replaceable elements
SP32 Series 300-450 HP
SP32 Series 300-450 HP

Industrial Electric

  • Three phase open drip motor options include 460/575 volt
  • Air end manufactured by Sullivan-Palatek
  • 460-volt, solid state with 115-volt control motor starter
  • Equipped with a Q1 microprocessor, the controller is able to handle the web access monitoring and sequencing of up to 12 compressors
  • The air intake filter includes an oversized dry type with easily replaceable elements
  • The compressor is flange mounted to motor C-face for positive alignment
VFD Series
VFD Series

Variable Frequency Drive Electric Compressors

  • Wide power range for 208V, 230V, 460V, and 575V
  • Pressure transducer motor speed control
  • Programmable digital outputs
  • Digital inputs
  • Programmable outputs: four relays, four transistors
  • Eight programmable parameter sets with S-curves, power off function, PID process controller, electronic motor protection, internal timer. Output frequencies up to 160 Hz with output voltage stabilization; switching frequencies up to 16kHz; output phase monitoring.
  • DC bus circuit connection, moto thermal sensor connection, hardware current line
  • The VFD has a soft start feature that maintains a low starting current. It reduces stress on the site power supply and also reduces motor wear.
  • The VFD system complies with the Electro-Magnetic Compatibility standard and is UL/CSA listed.
  • The VFD system is not limited to a fixed number of starts per hour.

A Trusted, Authorized Dealer of Sullivan-Palatek Air Compressors in Arizona, New Mexico, & Southern Nevada


One of the industry's top innovators, Sullivan-Palatek products offer a huge range of beautifully-designed air compressors. Since 1984, Sullivan-Palatek has been committed to providing well-built machines that offer exceptional value due to their reliability, efficiency, and long-lasting durability.

As an authorized dealer of Sullivan-Palatek products in Arizona & Nevada, Pioneer Equipment has the skills and accreditation required to sell, maintain, and service their entire line of industrial electric air compressors. Each Sullivan-Palatek air compressor comes with a comprehensive warranty.

For more information about purchasing a Sullivan-Palatek air compressor in Arizona and the Southern Nevada area, contact Pioneer Equipment today at (800) 523-9998 to speak to a member of our team. To request a quote, please complete the form on this page and a sales representative will contact you shortly.


Pioneer Equipment, Inc. is a family-owned company built on honesty, loyalty, and a commitment to quality service. We look forward to demonstrating to you our passion for delivering excellence!
